Welcome to another brief update from us at Excillum, where we would like to introduce our latest addition to the MetalJet family as well as show a few examples of SAXS applications using MetalJet sources. We also invite you to check out our updated web-site and finally, if you are interested in knowing what new colleagues we are searching for, check out the last section.
Björn Hansson, CEO
We are proud to present the latest addition to our product portfolio.
The new MetalJet C2 will complement the existing product range by offering an entry-level alternative, enabling more users to benefit from the MetalJet technology and its capacity. The MetalJet C2 is built on similar technology as the more advanced MetalJet D2+. The two models are compatible so that the user may upgrade their MetalJet C2 unit to become a MetalJet D2+ at a later stage.
With the tri-annual International Conference on Small Angle Scattering, SAS2018 just around the corner we think it is a good time to present a few examples of how SAXS instruments equipped with MetalJet X-ray sources can perform time resolved measurements traditionally only done on synchrotron light sources.
SEC-SAXS for Bio Applications
SEC-SAXS is an advanced technique where chromatography is used to separate the protein monomers from dimers and other complexes. This allows a short time window where the highest accuracy measurements of the molecular envelope can be performed. Recently this has been successfully performed by Scientists from University of Copenhagen using a BioXolver from Xenocs SAS equipped with a MetalJet. Please, click here for the appl. note!
S. Bucciarelli et al. Size-exclusion chromatography small-angle X-ray scattering (SEC-SAXS) of water soluble proteins on a laboratory instrument, J. Appl. Crystallogr. 2018, in press.
Material Science SAXS
Researchers at Slovak Academy of Sciences have performed a wide variety of time resolved SAXS studies on their custom Bruker AXS Nanostar instrument equipped with MetalJet. Examples of studies are in-situ test of strain gauges based on monolayer of colloidal gold with 10 sec. temporal resolution, crystallization and phase separation kinetics of P3HT during solvent annealing. In the latter example the temporal resolution of the GI-SAXS and GI-WAXS was 10 sec. and 2.5 sec. respectively which enabled a detailed study of the crystallisation and phase separation kinetics.
Scatter pattern of the P3HT:PCBM mixture. Size, position and shape all provide snapshot information to the kinetics of the reaction.
Summary of key parameters obtained from >100 scatter patterns at different crystallisations stages of the P3HT:PCBM mixture. It is clear that reactions happen fast and to capture the kinetics, an X-ray source enabling short measurement times is needed. The window of crystallisation as indicated in the figure is around 100 sec.
K. Vegso et al, Real-time SAXS study of a strain gauge based on a self-assembled gold nanoparticle monolayer, Sensors and Actuators A: Physical, 2016, 241, 87-95
K. Vegso et al, Kinetics of Polymer–Fullerene Phase Separation during Solvent Annealing Studied by Table-Top X-ray Scattering,, ACS Applied Materials & Interfaces 2017 9 (9), 8241-8247
Above images reprinted with permission from: K. Vegso et al, Kinetics of Polymer–Fullerene Phase Separation during Solvent Annealing Studied by Table-Top X-ray Scattering,, ACS Applied Materials & Interfaces 2017 9 (9), 8241-8247. Copyright (2017) American Chemical Society.
Conferences and Events
We have had a very busy event season, meeting many of you in person at conferences all around the world – which has been great! We have been talking to so many people, both old and new friends, and had so many engaging discussions regarding MetalJet technology and X-ray applications. We have had a great time and learned so much from you!
New web site
We are proud to present our new web site and invite you to visit us at:
Thank you for replying to the mailout in our effort to comply with GDPR regulations. As a reward we had a lucky draw among all who replied.
Congratulations to Dr. Graham Tizzard at University of Southampton, the winner of a pair of BOSE QuietComfort II!
Career @ Excillum
We have welcomed several new colleagues here at Excillum recently, and we still have some open positions! Maybe you will become our new team member?
Wishing you all the best and looking forward to seeing you again soon, maybe already at SAS2018!
The Excillum Team
